G4020F Series Fiber Laser Cutter not only has powerful cutting capacity, flying cutting speed, low operation cost, excellent stability, high-quality processing and strong adaptability, but also capable of processing 4m*2m sheet plate
l Highest-efficiency fiber laser cutter, the specialist in sheet metal cutting.
l Low operation cost and free of maintenance.
l The Fourth Generation fiber laser cutter, create a new era of sheet metal processing
High cutting speed 40m/min for 1mm thickness stainless steel. 85m/min for 0.5mm thickness stainless steel.
High performance Fiber transmission and flexible processing;capable of cutting any shape of materials with high quality;suitable for cutting brass, aluminum and other high reflecting materials.
High cost performance High cutting speed and low running cost, fast paying you back for your investment.
Low air consumption Save power and more environmental; power consumption is only 20% to 30% of CO2 laser cutter.
Free of maintenance No reflecting mirror and no need to adjust the light path.
| MODEL | G4020F |
| Processing surface (L × W) | 4000 mm × 2000 mm |
| X axle stroke | 4030 mm |
| Y axle stroke | 2020 mm |
| Z axle stroke | 120 mm |
| Positioning accuracy of X, Y and Z axis | ±0.03 mm/m |
| Repeated location accuracy of X, Y and Z axis | ±0.02 mm |
| Maximum positioning speed of X and Y axis | 169 m/min |
| Weight of CNC laser cutter | 14T |
| X/Y axis max. acceleration | 1.2G |
| Maximum load of worktable | 1600 kg |
| Phase | 3 |
| Rating voltage of power supply | 380 V |
| Frequency | 50 Hz |
| Total protection level of power supply | IP54 |
| Dimension (L*W*H) | 11200mm*3500mm*2000mm |
The G4020F Series Fiber Laser Cutter is widely used in metal working in different industries, auto ,steel, construction machines , elevator and other industries. It has earned many famous customers worldwide , including China Aerospace Group ,Hitachi, Benz Auto and so on.
Han’s Laser has developed Zero Second Perforation Tech, Flying Cutting Processing Tech, Leapfrog Cutting Tech and Cutting Stainless Steel and Aluminum with Compressed Air, which reduce cutting cost,improve cutting efficiency and make more profits for our customers.
